Digilent Audio Adapter for Analog Discovery
Digilent Audio Adapter for Analog Discovery provides an easy method of connection to analyze audio signals with the Analog Discovery oscilloscope instrument. It is equipped with one Mono and one Mono/Stereo Jack connector connected to the inputs of the oscilloscope and a 2×15 MTE connector to pass through all other signals.
Part no.: 410-405
Key features
- One 3.5 mm Mono Audio Jack connector
- One 3.5 mm Stereo Audio Jack connector
- 2 Mono vs 1 Stereo Selection Jumper
- Pass through Connector for the Digital I/O Signals, Power Supplies, and Triggers
Applications
- Test Measurement
